Knauf MaxSpace

Less wall, more space. The ideal profile for more profit per m²

With Knauf MaxSpace, it's smart and sustainable building. This innovative, slim wall system significantly optimizes the usable area (GFA) of buildings. Compared to a traditional residential partition wall 205 mm thick, Knauf MaxSpace delivers a space gain of 8 cm. For 100 units with a wall length of 5 meters, this means an additional 40 m² of usable space.

The Knauf MaxSpace system is constructed from a standard CW-50 profile, fitted with bio-based coir felt on both sides and an additional steel flange. Plasterboards are then attached to this. The coir felt has an important role in sound insulation. The coir felt provides acoustic decoupling, preventing sound from being transmitted directly through the wall posts. The total wall thickness is only 125 mm.

Knauf MaxSpace is also a sustainable choice. Not only does it use biobased material, but it also uses less material. In fact, three linear meters less steel is used per square meter and one square meter less glass wool.

The benefits

• Space-saving profile with gains of up to 8 cm per room
• The slimmest wall system with adequate sound values Rw = 62.8 dB, sufficient for a Dn;T;A,k = 52 dB
• Fire performance that meets EI60
• Better plating with a high-quality and impact-resistant top plate
• Sustainable choice: the profile features biobased coir felt and uses less material.

System Structure

• Knauf MaxSpace profile standard 2800mm or other lengths on request
• Knauf MaxSpace profile weighted
• Knauf UW75 profile 4.0 mm, or Knauf UW75 profile with sealing tape 4.0 m
• Knauf A-Plate 12.5 mm and Knauf Diamond Board 12.5 mm
• Diamond Board screws XTN 3.5×23 mm and 3.5 x 33 mm
• Glass wool Knauf Acoustifit 60 mm

Application

By combining a low thickness with excellent performance in terms of sound insulation and fire resistance, the wall is optimally suited for projects such as apartments, hotels, studios and student housing.

If all Knauf components are applied, the KnaufZeker® warranty.
